The TENET, paired with an aftermarket speedometer, is compatible with your motorcycle if it includes configuration options (wheel circumference, number of pulses, engine revolutions).

Main Features:

• Engine RPM signal
• Speed signal from the bridge inductive sensor
• Neutral indicator
• Gear position indicator (1/2/3/4/5/6)
• Fuel level indicator (reserve warning light)
• Fuel level indicator (fuel gauge)
• Fuel level adjustment (reserve)
• Low battery indicator
• Turn signal indicator (right, left, hazard)
• High beam indicator
• Position light indicator
• Lamp control indicator
• ABS indicator
• Temperature indicator
• Oil pressure indicator
• Choke indicator
• Combined lighting

Additional Specialized Functions:

1. Connection restricted by a secure password (letters, numbers, symbols). Only your smartphone can connect.
2. Anti-theft mode: Bluetooth connection is cut off (e.g., loss of range, manual disconnection), or if the TENET BLE app is closed. This feature enhances security by preventing unauthorized use of the motorcycle when the associated smartphone is absent.
3. Activation of the motorcycle’s ignition via Bluetooth with On/Off control.
4. Activation of the ignition contact and control of the START starter relay via Bluetooth.

Applications:

• Configuration on Android via Google Play
• Configuration on iOS via App Store

Technical Specifications

Power Supply

Input Voltage: 12V DC (motorcycle battery)

Standby Current: <50mA

Active Current: <200mA

Connectivity

Protocol: Bluetooth Low Energy (BLE) 4.0+

Range: ~10 meters in open field

Security: Customizable 4-character password

Outputs

Terminal A: ON/OFF Contact (12V, 10A max)

Terminal B: Timer Starter (1s, 12V, 10A max)

Environment

Operating Temperature: -20°C to +60°C

Protection Rating: IP54 (splashproof)

Dimensions: 120mm x 80mm x 35mm

Compatibility

12V motorcycles only

Compatible with iOS 11+ and Android 6.0+

Compatible with odometers aftermarket and original
